Vedaa Prefab Technologies Private Limited With a sincere effort to grow into prominence delivering superior quality products and services, we are one of the most successful brands in the industry. Vedaa Prefab Technologies Private Limited was established in the year 2016 and since then, the company has been adorned countrywide as a highly reputed manufacturer and supplier of a massive range of quality PUF Insulated Panels,Roofing panels,Clean Rooms, Cold Rooms and Prefabricated Shelters, Portable cabins, Doors Solution.
At present, as an ISO 9001:2015 certified company, we are supplying these products to thousands of our clients from all over the country, including some highly reputed corporate clients such as Heritage, L&T, etc. Our clients rely on us as we constantly adhere to international quality standards with all our products. Their confidence is also favored by our brilliant expertise in manufacturing customized products as per exact specifications of the clients.
We are considered in the market to be one of the leading manufacturers and suppliers of these PUF Insulated Panels. For the purpose of living up to this reputation, we use finest raw materials and modern machinery. Finding their application in several industries, for the purpose of building roofs and wallsGet Details
Sandwich Panel are typically single piece, prefabricated, modular, factory made units which consist of an insulating layer of rigid polyurethane foam or high density Rockwool between two layers of metal sheet. Insulation core provides effective thermal insulation and long lasting strong bonding for better structural stability to facilitate higher loading & wider spans. It is highly suitable for energy saving, faster
|Length of Panel||Up to 10.5 MTR any size|
|Width - Wall||Supply width 1195mm (Standard) Covering Width 1175 mm / Customized|
|Width - Roof||Supply width 1060mm standard Covering width 1000mm|
|PPGI (Pre Powder coated galvanized sheet) Thickness (MM)||0.4 mm/0.45 mm /0.5mm /0.6mm /0.7mm /0.8mm|
|Puf Core Thickness (mm) Wall||40, 50 , 60, 80, 100, 120, 150|
|Puf Core Thickness (mm) Roof||30,40, 50 , 60, 80, 100, 120, 150|
|U Value (w/m2 K)||0.53 , 0.43, 0.33, 0.28 , 0.22, 0.18, 0.15|
|R Value (h-ft2-f/btu)||11, 13, 16, 20, 26, 30, 3, 8|
|Facia Options||PPGI, PPGL, Alu, Cement sheet, SS , Laminate Sheet|
|Thermal conductivity at 10c* mean temperature (w/m*k)||0.023|
|Compressive strength at 10% deformation (kg/cm2)||2.1|
|Bending strength (kg/cm2)||0.4 mm/0.45 mm /0.5mm /0.6mm /0.7mm /0.8mm|
|Tensile strength (kg/cm2)||3.7|
|Adhesive strength (kg/cm2) foam to Steel||2.9|
|Water absorption(volume%)||0.2% at 100% RH|
|Closed Cell Content (%)||92-95%|
|Vapour permeability at 90% RH & 38 Oc (Gms / Hr.sqm) - Fire Class||0.12 - Fire Retardant|
Rigid polyurethane foam Most Popular, Widely used, Ideal Insulator. It is thermosetting Material when exposed to fire, does not drip or melt; forms a strong carbonaceous char that protects the core and prevents spread of flame. additions of FR Agents further augment fire retardant properties. It is CFC free & self extinguishing. Conforms to IS-12436-88
Polyisocyanurate Foam Offers higher fire rating and is non-ignitable. better closed cell structure offered by trimerisation process offers better thermal performance. It is CFC free, Longer lasting, hygienic and food safe. Ideal for Cold Rooms.
1. Improved Thermal & Acoustic Insulation
2. Use as Structural Insulation Panel (SIP) eliminating the need of masonry construction.
3. Closed cellular structure- inherently water resistant.
4. Available in any length depending on transport logistics
5. External & Internal steel facing is the best effective vapour barrier & can be washed and disinfected
6. All weather proof & long life *Save energy.
7. Self extinguishing property avoids spread of Flame
8. Resistance to corrosion, Termite, Physical Impact and fungus.
9. CFC free & zero Ozone depletion property.
